Safety Shoe High Voltage Resistance Testing Machine Electrical Insulation Testing Equipment
- Type: Safety Shoe Electrical Insulation Tester
- brand name:HOTOTECH
- place of origin:Hubei, China
- Accuracy:±0.1%
- customized support:ODM, OEM
- power:500W
- Protection Class:IP55
- Voltage:220 V
- warranty:1 Year
Instrument Introduction:
The high voltage resistance testing machine is used to test safety shoes, protective work shoes, and test samples with a certain high voltage. It evaluates whether the test sample has high voltage insulation resistance by measuring the leakage current of the test sample or judging whether there is a phenomenon of electrical breakdown of the test sample.
Main functions:
The test can complete the high voltage resistance performance of protective shoes that meet European, American, national, and additional standards for electric shock breakdown.
Reference standard:
GB/T20991-2007, ASTM F2413-05, ASTM F2412-18a
CSA-Z195, ISO EN20344-2011, GB/12011-2009, GB/T21148-2020 and other standards.
Technical specifications:
| Pre setting of leakage current; The upper limit of leakage current can be set arbitrarily from 0 to 10mA. | |
| Firing voltage | adjustable from 0 to 20KV |
| Firing time | 0-99 seconds can be set |
| If the leakage current exceeds the preset current, the power will automatically shut down and an alarm will be triggered | |
| Volume | 1150 * 460 * 800mm |
| Weight | 69kg |
| Power supply | AC220V, 10A |
