High Temperature & Ignition Flame Resistance Test Machine for Goggles Faceshield
- Type: Goggles Ignition Tester
- place of origin:Hubei, China
- Accuracy:0.1%
- Application:Universal Testing, Plastic Testing, Lab Testing, Laboratory Testing, Electrical Testing
- customized support:OEM, ODM, OBM, Software Reengineering
- power:100W
- Protection Class:IP65
- Voltage:220 V
- warranty:1 Year
Safety Eyewear / Goggles Flame Retardant Tester-steel rod heat tester
Verifies fire resistance with 650°C heating rod contact. Complies with ANSI/EN/ISO standards. Ideal for QC labs ensuring compliance. Includes digital timer and calibration certificate.
Application:
Safety Glasses / Goggles / Face Shield / PPE Testing / Quality Control / Laboratory.
ANSI Z87.1 Heated Rod Test Procedure for Safety Eyewear:
1. Sample Mounting: Secure the goggle/lens sample vertically.
2. Rod Specification: Use a cylindrical steel rod with a 6 mm diameter tip.
3. Heating: Heat the rod tip to (650 ± 20)°C.
4. Application: Apply the heated tip perpendicularly to the lens surface with light pressure (≤ 1 N).
5. Duration: Maintain contact for (60 ± 1) seconds.
6. Press the heated face ofthe rod against a surface of the protector (the contact force being equal to the weight ofthe rod) for 5.0 ±0.5 seconds, and then remove it.
7. Pass/Fail Criterion: protectors shall not ignite or continue to glow once the rod is removed. Each externally exposed material (exclusive of textiles or elastic bands) shall be tested.
ANSI Z87.1 / EN 166 /EN168 / CSA Z94.3 / AS/NZS 1337/ ISO 16321/IEC/EN 60695-2-13/ASTM D3874/ISO 11925-2
| Heating Rod Dimensions: | 6×300 mm (0.24×11.81 in) |
| Heating System Temperature: | 650±20°C (1202±36°F) |
| Heating zone length: | ≥50 mm (1.97 in) |
| Thermocouple Position: | Mounted 20±1 mm (0.79±0.04 in) from rod end |
| Contact force: | Rod's self-weight only |
| Duration: | 5.0±0.5 seconds |
| Timing accuracy: | ±0.1 sec |
