Foam firmness testing equipment

Mattresses Foam Firmness and Indentation Hardness Tester

HT-F09
The HOTOTECH HT-F09 Laboratory Grade Mattress Foam Firmness Testing Equipment is a high-precision solution designed to evaluate the indentation hardness and firmness of foam and mattresses. Equipped with an advanced data recording function, this equipment seamlessly measures hardness grades before and after rolling tests. Built for strict quality control, it fully complies with premier global standards including ASTM D3574, ASTM F1566, and ISO 2439, ensuring reliable, repeatable data for mattress and foam manufacturers worldwide.
minimum order
1 set
Quantity:
$9999.00 - $9999.00 / set
Contact Now
add to cart

Foam Firmness and Indentation Hardness Tester for Mattresses

Purpose:

TheHOTOTECH HT-F09 Laboratory Grade Mattress Foam Firmness Testing Equipment is a high-precision solution designed to evaluate the indentation hardness and firmness of foam and mattresses. Equipped with an advanced data recording function, this equipment seamlessly measures hardness grades before and after rolling tests. Built for strict quality control, it fully complies with premier global standards including ASTM D3574, ASTM F1566, and ISO 2439, ensuring reliable, repeatable data for mattress and foam manufacturers worldwide.

Product Purpose & Applications

  • Foam Firmness Evaluation: Measures the indentation hardness and load-bearing performance of flexible cellular polyurethane foam.

  • Pre & Post-Roll Testing: Specifically designed to measure mattress hardness grades before and after durability rolling tests to assess structural changes.

  • Smart Data Recording: Features an automated data logging function to record, analyze, and export test results for seamless laboratory quality control.

  • Multi-Standard Compliance: A versatile laboratory tester that handles international protocols for foam, bedding, and automotive seating materials.

Technical specifications:




Range of indentation hardness testing



0-2224N



Effective travel of pressure plate



750mmx0.1mm



Speed (mm/min)



0.05 to 500 mm/min



Speed rate



+0.2%



Rotation speed (mm/min)



500mm/min



Accuracy deviation range of test results



± 0.5% of the indicated value or ± 0.1% of the full range. When there is no weight applied, the numerical value is not displayed



Load sensor



When there is no weight applied, the numerical
value is not displayed



Maximum travel limit



Upper and lower limiters -2 points



Standards



AS 2281, ASTM F1566, ASTM D3574--Test B
IS0 3386,1S0 2439,BS EN 1957:2000
GB 10807
JS K 6400



Company Profile:
