Mattress Hardness Grade Distribution Tester
Discover our Digital Mattress Hardness Grade Distribution Tester. Compliant with ASTM F1566 & EN 1957 standards. Features a high-precision pressure mapping system for spring & foam mattress factory testing. Request a quote today!
Product Introduction:
This advanced digital testing machine is specifically engineered to evaluate and determine the hardness grade, firmness distribution, and surface pressure mapping of various types of mattresses. It provides mattress manufacturers and quality control labs with precise, data-driven insights to ensure compliance and comfort.
Technical parameter:
| Load element capacity | 2kN imported sensor | Position measurement device | Panasonic laser displacement sensor (3 sets) |
| Load element accuracy | ≤0.5% | Displacement measurement accuracy | ±1mm |
| Electric cylinder stroke | 500mm | The test results display | Automatic digital and curve display |
| electric machinery | 400W Panasonic servo motor | Test frequency | 1-999999 can be set arbitrarily |
| Driver | 400W Panasonic servo drive | Applicable sample size | 2000*1800*400mm(L*W*H) |
| Screw rod | ball screw | weight | About1000kg |
| Display mode | Computer control, operating in Windows mode | Power | 2kw |
| Adjustable speed | 0.1-250mm/s | Power supply | AC 220V |
| control mode | Independently developed circuit boards and software, closed-loop control | ||
| Shutdown mode | Upon reaching the set number of times and travel limit, the test is completed and the machine automatically stops | ||
