Digital Mattress Hardness Grade Distribution Tester
Product name:
Digital Mattress Hardness Grade Distribution Tester Machine - ASTM F1566/EN 1957 Compliant with Pressure Mapping System
Product Introduction:
This state-of-the-art testing machine is specifically engineered for factory-level quality control, R&D, and compliance testing of various mattresses (including innerspring mattresses, foam mattresses, latex mattresses, and hybrid mattresses). It is widely utilized across the following industries and sectors:
Mattress Manufacturing Plants: For rigorous batch testing, quality assurance (QA), and verifying firmness consistency before shipment.
Research & Development (R&D) Labs: To analyze body pressure distribution and optimize ergonomic designs for new mattress models.
Third-Party Inspection & Certification Bodies: To conduct standardized compliance testing according to global market regulations.
Hospitality & Commercial Procurement: Used by premium hotel groups, inns, and restaurant-associated accommodation chains to audit supplier quality and ensure a consistent sleep experience for guests.
Core Features:
Dual Standard Compliance: Fully compliant with ASTM F1566andEN 1957 international testing standards for mattress durability and firmness classification.
Advanced Pressure Mapping System: Equipped with high-precision sensors that provide real-time, visual color maps of hardness grade distribution and load-bearing performance.
Digital Intelligent Control: Features a user-friendly digital interface for automated testing cycles, precise data logging, and instant PDF report generation.
Versatile Application: Highly adaptable, delivering precise data for both heavy-duty spring mattresses and high-density memory foam/latex mattresses.
Technical parameter:
| Load element capacity | 2kN imported sensor | Position measurement device | Panasonic laser displacement sensor (3 sets) |
| Load element accuracy | ≤0.5% | Displacement measurement accuracy | ±1mm |
| Electric cylinder stroke | 500mm | The test results display | Automatic digital and curve display |
| electric machinery | 400W Panasonic servo motor | Test frequency | 1-999999 can be set arbitrarily |
| Driver | 400W Panasonic servo drive | Applicable sample size | 2000*1800*400mm(L*W*H) |
| Screw rod | ball screw | weight | About1000kg |
| Display mode | Computer control, operating in Windows mode | Power | 2kw |
| Adjustable speed | 0.1-250mm/s | Power supply | AC 220V |
| control mode | Independently developed circuit boards and software, closed-loop control | ||
| Shutdown mode | Upon reaching the set number of times and travel limit, the test is completed and the machine automatically stops | ||
