Cornell Mattress Durability Tester
Shop the professional Cornell mattress durability tester compliant with ASTM F1566. Features a digital counter for 200,000 cycles mattress fatigue testing.Shop the professional Cornell mattress durability tester compliant with ASTM F1566. Features a digital counter for 200,000 cycles mattress fatigue testing.
Product Introduction:
Use specific loading blocks to repeatedly impact the mattress, simulate the impact of the human buttocks on the spring mattress during use, to evaluate its fatigue life performance and the firm retention of the spring.
Product Uses:
This professional-grade testing machine is specifically designed to evaluate the long-term fatigue life, structural durability, and spring firmness retention of innerspring mattresses, box springs, and foam mattresses. By simulating real-world usage, it helps manufacturers ensure ultimate product reliability.
Human Impact Simulation: Utilizes a standard-specified dual-hemispherical loading block to repeatedly impact the mattress surface, precisely replicating the repetitive impact and load of human buttocks during long-term use.
Fatigue Life Evaluation: Measures and analyzes changes in mattress thickness (sagging), structural deformation, and hardness retention after up to 200,000 cycles (or custom cycles).
Factory Quality Assurance (QA/QC): Ideal for mattress manufacturing plants to conduct batch compliance testing before mass distribution.
R&D Performance Testing: Enables bedding research laboratories and premium mattress brands to benchmark new spring systems and mattress structures against global standards.
Core Features:
Strict ASTM F1566 Compliance: Engineered fully in accordance with the ASTM F1566 standard, ensuring test data is globally recognized by international buyers and certifying bodies.
Heavy-Duty 200,000 Cycles Capability: Built with an industrial-grade drive system capable of continuous, high-intensity operation to seamlessly complete standard 200,000-cycle fatigue tests.
Smart Digital Counter & Automation: Equipped with an intelligent digital counting and control system that automatically stops the machine when the preset cycle count is reached, allowing for unattended laboratory operation.
High-Precision Load & Displacement Measurement: Features premium sensors to accurately track load changes and deformation depth, delivering reliable data reports.
Technical parameter:
| The pressure applied to the mattress is read by a pressure transmitter, with a pressure range of 300KG |
| The computer program compiles a complete test report based on the data from the pressure transmitter and position transmitter |
| The computer synchronizes monitoring instrument measurement data and can output Excel data reports |
| Automatic adjustment of height loss in 7 stages: 200, 6000, 12500, 25000, 50000, 75000, 100000 |
