Testing Standard It's confirm IEC61215 & IEC61730 testing standard.
Purpose To determine the ability of the module to withstand the effects of long -term penetration of humidity & the ability of the module to withstand thermal mismatch, fatigue and others stresses caused by repeated changes of temperature.
Testing Chamber Advantage
Have three function:
Damp heat testing ( double 85℃ testing)
Thermal cycling testing
Humidity freeze testing
Testing Chamber Structure Introduce
Inner chamber material: SUS # 304 high temperature resistant stainless steel plate;
Insulation Material: High density hard PU foaming and glass insulation cotton On the door with the view window, the view window welding in the middle of the door , prevent moisture seeping in to the insulation;
The chamber inner size: 1.0m×2.2m×1.3m ( W×D×H);
The chamber inner can put 8 pcs solar panel;
Refrigerant: use the newest HFC environmental protection refrigerant;
Temperature range: -40 to 100℃, and the temperature fluctuation ≤±1℃, the deviation ≤±1℃ and the uniformity: ≤±1℃;
Humidity range: 30 to 98%RH, the relative humidity deviation:±3%FS, deviation 85±2%RH, 90±2%RH, Humidity fluctuation : ±2%RH, humidity uniformity: ≤2%RH;
The electricity: 380V 50HZ;
Damp heat testing: common moisture point: 85℃/ 85%RH, the sustainable time ≥1000H 90℃/95%RH, the sustainable time ≥1000H;
Humidity freeze temperature go up & go down speed rate:
A.from 25℃ to 85℃ , the speed is 100℃/h(1.6℃/Minute) B.from 85℃ to 0℃,the speed is 100℃/h (1.6℃/Minute) C.from 0℃ to -40℃, the speed is 200℃/h (3.3℃/Minute) D.from -40℃~0℃, the speed is 200℃/h (3.3℃/Minute) E.from 0℃ to 85℃, the speed is 100℃/h (1.6℃/Minute) F.Testing cycle times:50
6.Thermal cycle testing: the temperature change rate of module surface should not more than 100℃/ h (1.6℃/ Minute), testing cycle times: 200
Control system:
Control system: automatic calculus, Touch screen control and display the testing data
Real-time curve display: with the program set time, adjustable curve sampling record cycle, set value curve & actual running value curve
Real-time set display: with the perform program number, staging, remain time ,cycle times, temperature & humidity value
Communicate interface: RS485 communicate interface, can connect to the computer , the data can save, print and download
Use the U disk can copy the testing data and transfer to the computer
Controller: heating/ humidification/ dehumidification/ cooling etc function completely independent control, and save the energy
Language: With English
When Power off, It's will automatic reset and memory function
HTPV-17 Thermal Cycling Test / Humidity Freeze Test
HTPV-17
0.00~0.00
Testing standard It’s confirm IEC61215 & IEC61730 testing standard
Purpose To determine the ability of the module to withstand the effects of long -term penetration of humidity, & the ability of the module to withstand thermal mismatch , fatigue and others stresses caused by repeated changes of temperature
